Hanwha HCB-7000A 4MP Wisenet HD+ Box Camera
4MP Wisenet HD+ Box Camera
$189.00 USD
Wisenet HD+ 4MP box camera, AHD or CVBS formats are available, RS485 /Coaxial Control, true D/N, 24VAC/12VDC (Require 4MP or higher CS Mount Lens).
Available as Hanwha Vision part number HCB-7000A.
Technical specifications
Video
| Specification | Value |
|---|---|
| Imaging Device — Size | 1/3" |
| Imaging Device — Type | CMOS |
| Resolution | 2560×1440 |
| Max. Framerate(NTSC/PAL) | 30fps/25fps |
| Min. Illumination — Color(1/30sec, 30IRE) | 0.16 |
| Min. Illumination — BW(1/30sec, 30IRE) | 0.009 |
| Video Out | CVBS: 1.0Vp-p / 75Ω composite, 720×480(N), 720×576(P) for installation, BNC: AHD |
| Video Transmission Distance | 500m(5C2V Coaxial Cable) |
Lens
| Specification | Value |
|---|---|
| Focus Control | Manual |
| Lens Type | DC auto iris(IR corrected) |
| Mount Type | C mount, CS mount |
Operational
| Specification | Value |
|---|---|
| Day & Night | Auto(ICR) |
| Backlight Compensation | BLC, HLC, DWDR |
| Digital Noise Reduction | 2DDNR |
| Motion Detection — Quantity | 4ea |
| Privacy Masking — Quantity | 2ea |
| Gain Control | Low, Middle, High, Very High |
| White Balance | ATW, AWC, Manual, Indoor, Outdoor |
| Electronic Shutter — Speed Range | 1/30~1/12,000sec(N), 1/25~1/12,000sec(P) |
| Video Rotation | Flip, Mirror |
| Serial Interface | RS-485 |
| Alarm Interface — In/Out | Output 1ea |
| Coaxial Protocol | ACP, CVBS |
Analytics
| Specification | Value |
|---|---|
| Analytics Events — Normal | Motion detection |
Environmental & Electrical
| Specification | Value |
|---|---|
| Operating Condition — Temperature | -10°C~+55°C(+14°F~+131°F) |
| Operating Condition — Humidity | 0~90% RH(non-condensing) |
| Input Voltage | 24VAC, 12VDC |
| Power Consumption — 12VDC | Max 3.6W |
| Power Consumption — 24VAC | Max 3.6W |
Mechanical
| Specification | Value |
|---|---|
| Color | Ivory, Black |
| Material | Aluminum, PC(Polycarbonate) |
| Product Dimensions | 59.6×68.4×92.7mm(2.35×2.69×3.65") |
| Product Weight | 186g(0.41lb) |
Ver
| Specification | Value |
|---|---|
| Ver | 202410 |
Specifications from official manufacturer documentation. Some values may vary by hardware configuration.
