Hanwha HCP-6320A AHD PTZ
,

Hanwha HCP-6320A AHD PTZ

AHD PTZ

$1,333.00 USD

Request a quote

Wisenet HD+ 2MP, Full HD(1080p) 30fps PTZ camera, Optical zoom lens 32X (4.44~142.6mm), true WDR 120dB, RS485/Up coax (ACP protocol only) PTZ control, true D/N, 24VAC.

Available as Hanwha Vision part number HCP-6320A.

Technical specifications

Video

Specification Value
Imaging Device — Size 1/2.8"
Imaging Device — Type CMOS
Resolution 1920×1080
Min. Illumination — Color(1/30sec, 30IRE) 0.2
Min. Illumination — BW(1/30sec, 30IRE) 0.01
Video Out CVBS: 1.0Vp-p / 75Ω composite, 720×480(N), 720×576(P) for installation, BNC: AHD

Lens

Specification Value
Focal Length (mm) 4.44~142.6
Optical Zoom Ratio 32x
Max Aperture Ratio (F number) — Wide 1.6
Max Aperture Ratio (F number) — Tele 4.4
Min. Object Distance 1.4m(4.59ft)
Focus Control Manual, Auto, One push
Lens Type DC auto iris(IR corrected)

Pan / Tilt / Rotate

Specification Value
Pan / Tilt / Rotate Range — Pan 360° Endless
Pan / Tilt / Rotate Range — Tilt -15°~195°
Pan Speed — Preset 700°/sec
Pan Speed — Manual 0.024°/sec~200°/sec
Tilt Speed — Preset 700°/sec
Tilt Speed — Manual 0.024°/sec~200°/sec
Sequence Preset
Preset Accuracy ±0.2°

Operational

Specification Value
Day & Night Auto(ICR)
Backlight Compensation BLC, HLC, WDR
Wide Dynamic Range (dB) 120
Digital Noise Reduction SSNRⅢ
Digital Image Stabilization Support
Defog Support
Motion Detection — Quantity 1ea
Motion Detection — Shape Rectangualr zones
Privacy Masking — Quantity 12ea
Privacy Masking — Shape Rectangular zones
Gain Control Low, Middle, High
White Balance ATW, AWC, Manual, Indoor, Outdoor
Electronic Shutter — Mode Auto, ESC, Manual
Video Rotation Flip
Serial Interface RS-485
Alarm Interface — In/Out Input 4ea, Output 2ea
Alarm Triggers Analytics
Alarm Events When Alarm Trigger Occurred Alarm output
Coaxial Protocol ACP

Analytics

Specification Value
Analytics Events — Normal Motion detection, Virtual area(Appear, Disappear), Virtual area(Enter/Exit), Virtual line

Environmental & Electrical

Specification Value
Operating Condition — Temperature -10°C~+55°C(+14°F~+131°F)
Operating Condition — Humidity 0~90% RH(non-condensing)
Storage Condition — Temperature -50°C~+60°C
Storage Condition — Humidity 0~90% RH(non-condensing)
Input Voltage 24VAC
Power Consumption — 24VAC Max 20W

Mechanical

Specification Value
Color Ivory
Material PC(Polycarbonate)
Product Dimensions ø152.0×218.0mm(ø5.98×8.58")
Product Weight 3300g(7.28 lb)

Ver

Specification Value
Ver 202410

Specifications from official manufacturer documentation. Some values may vary by hardware configuration.
