Mounts

Threaded ACI adapter

• Compatible with Axis ¾″ NPS (M25) conduits
• Spring clip included
• Stainless steel

AXIS ACI Conduit Adapter 3/4″ NPS is used for attaching ¾″ NPS conduits to Axis products with a ¾″ conduit interface.

For U-shape cable protection

• U-shaped cable entry
• Sold in packs of five

Mechanical adapter providing a U-shaped 30 mm wide cable entry for use when U-shape cable protection is required.

1 pair marine-grade (SS316L) stainless steel straps with TX30 screw interface for ease-of-installation. Length 1450mm (57″). Width 14.3mm (0.57″). Thickness 0.68mm (0.03″). Compatible with a wide range of Axis pole mounts. Pole diameter range 100-410mm (4″-16″) when used with AXIS T91B47 Pole Mount.

For a single illuminator

Mounting on walls and poles

AXIS T91B47 Pole Mount for indoor and outdoor installations, for poles with diameter between 50-150mm (2″-6″). Includes 1 pair of AXIS Stainless Steel Straps 570mm (22.5″) with TX30 screw interface for ease-of-installation. AXIS T91B47 is directly compatible with a wide range of Axis cameras.

• Suitable for wide range of pole diameters
• Safe and easy to install
• IK10-rated vandal resistance
• NEMA 4X-rated corrosion protection
• Axis stainless steel straps included

Telescopic ceiling mount with swivel action

• For outdoor and indoor
• Adjustable length
• Swivel action
• Robust and safe
• Vandal and corrosion resistant: IK10- and NEMA 4X-rated

AXIS T91B50 Telescopic Ceiling Mount is compatible with all Axis PTZ dome cameras and outdoor models of Axis fixed domes.

With 1.5″ NPS thread

• Indoor and outdoor use
• Available in two lengths
• Enables use of various mounts
• Powder-coated aluminum

With 1.5″ NPS thread

• Indoor and outdoor use
• Available in two lengths
• Enables use of various mounts
• Powder-coated aluminum

Robust and safe installation

• Indoor and outdoor use
• IK10 rating
• Easy to install
• Flexible cable routing
• Aluminum

AXIS T91B63 Ceiling Mount includes a removable AXIS T94A01D Pendant Kit* and AXIS T91A6 Pipe Seal. The mount is compatible with Axis pendant kits with 1.5″ NPS or NPT inner thread and ACI ¾″ conduit adapters. The cables can be routed through the back, or from the side by using a conduit connection.

Wall mount with 1.5″ NPS thread

• Flexible cable routing
• AXIS T91A6 Pipe Seal included
• Aluminum

AXIS T91D61 Wall Mount 1.5” NPS is compatible with Axis fixed dome pendant kits and ACI ¾″ conduit adapters. The cables can be routed through the back or from the side using a conduit connection.

For Axis fixed dome pendant kits

• 1.5″ NPS thread
• Flexible cable routing
• Indoor and outdoor use
• Aluminum

AXIS T91E61 Wall Mount is compatible with Axis fixed dome pendant kits. The cables can be routed through the back or externally via the cut-outs at the base of the wall mount.

Made of marine grade-stainless steel

• Resistant to seawater and chemicals
• Indoor and outdoor use
• Marine grade stainless steel (SS 316L)
• For pole diameters of 100–410 mm (4–16 in)
• Stainless steel straps (SS 316L) included

AXIS T91F67 Pole Mount is made of marine grade, electropolished and coated stainless steel (SS 316L). This makes the pole mount resistant to impact and corrosion. The mount is ideal for stainless steel fixed dome cameras.

One pair of marine-grade stainless steel (SS316L) straps with TX30 screw interface is included.

Tiltable wall-mount for AXIS D2110-VE Security Radar and AXIS D2050-VE Network Radar Detector. Includes arm, AXIS T94R01P CONDUIT BACK BOX and conduit 260 mm (10 inch) cable kit.

Sparepart including the electronics module of the AXIS T92E20 housing including fan and screws.

For selected Axis PTZ cameras and AXIS Q37 Series

• Indoor and outdoor use
• Suitable for hard ceilings
• Enables use of various mounts
• ¾″ conduit hole on the side
• Aluminum

AXIS T94A02F Ceiling Bracket is compatible with Axis PTZ cameras and AXIS Q37 Series.

Mount for roof overhangs and soffits

• Outdoor-ready
• Suitable for plenum spaces

AXIS T94A02L Recessed Mount is designed for installations in roof overhangs and soffits. The metal back box with a ¾-inch hole for cable protection conduits makes the mount suitable for installations in plenum spaces.

For versatile mounting

• Flexible mounting
• Indoor and outdoor use
• Network cable coupler indoor included

AXIS T94F01M J-Box/Gang Box Plate is used for mounting a camera on 4″ square, 4″ octagon, single-gang, or double-gang junction boxes. It can also be used to mount compatible cameras on AXIS T98A17-VE Surveillance Cabinet, or AXIS T94P01B Corner Mount.

Robust design with cable protection

• For indoor and outdoor use
• Impact resistant
• Robust and safe

AXIS T94J01A Wall Mount is an aluminum mount suitable for Axis positioning cameras and positioning units. It is compatible with Axis ACI 3/4” conduit adapters, and offers six cable entries. Cables can be routed internally through the back or, by using a conduit connection, from each side or from the bottom. Use with optional accessories for mounting on poles or external corners.

For selected Q35 Cameras

• For mounting the camera on 1.5″ NPS threaded brackets
• Black, inside coating for reduced reflections
• Outdoor-ready
• Enables use of various mounts

Outdoor pendant kit for mounting the camera on 1.5″ NPS threaded brackets.

For roof overhangs and soffits

• Suitable for drop ceilings and soffits
• Indoor and outdoor use
• Quick and easy installation

AXIS T94M02L Recessed Mount is designed for outdoor installations in overhangs and soffits, and has metal back box with a ¾″ (M25) conduit hole.

For AXIS P47 Camera Series

• Indoor and outdoor use
• Fits on poles, parapets, and outer corners
• For mounting on 1.5″ NPS threaded brackets

AXIS T94N02D Pendant Kit allows AXIS P4705-PLVE and AXIS P4707-PLVE Panoramic Cameras to be mounted on poles, parapets and outer corners using 1.5″ NPS threaded brackets.

Mounting on corners

• Indoor and outdoor use
• Aluminum

AXIS T94P01B Corner Bracket is a corner mount for indoor and outdoor use. When used with AXIS P14 Network Cameras, it requires AXIS T94F01M J-Box/Gang Box Plate.
