AXIS A4612 Network Bluetooth® Reader

AXIS A4612 Network Bluetooth® Reader

AXIS network access control

  • It supports most types of RFID card standards with 13.56MHz credentials
  • IP55-rated, ready for installation both indoors and outdoors
  • With PoE, you can connect to the closest network switch with a single cable for both power and connectivity- no need to wire back to the door controller
  • | AXIS Product Number: 03072-001

$529.00 USD

Request a quote

AXIS A4612 Network Bluetooth® Reader offers convenient access using your mobile phone. It supports most types of RFID card standards with 13.56MHz credentials. IP55-rated, ready for installation both indoors and outdoors. With PoE, you can connect to the closest network switch with a single cable for both power and connectivity- no need to wire back to the door controller.

AXIS Product Number: 03072-001

Technical specifications

Key specifications: IP55 rated; operating range -40 to 60 °C. Manufacturer part number 03072-001.

Spec

Specification Value
Reader protocol –
Credential technologies MIFARE Classic, MIFARE DESFire EV1, MIFARE DESFire EV2, MIFARE DESFire EV3, MIFARE Plus
Credentials Bluetooth, CardNr, Tag
Integrated keypad –
DC input voltage 12-12 V
Power over Ethernet Yes
DC Output – Max 12
Cable (length) 2900 mm
IP rating IP55
Alarm inputs/outputs 2/0
Relays 1
Height 133 mm
Width 50 mm
Depth/length 27 mm
Weight of sales unit (without box) 500g
Safety approvals EN: 62311, IEC/EN 62368-1 ed.3
Product label markings CE, FCC, KC, MIC Telecom, NCC, RCM, UL, VCCI
Sustainability –
Operating temperature -40 to 60 °C
Outdoor Ready Yes

Specifications from official manufacturer documentation. Some values may vary by hardware configuration.
