5MP (2560×1944) resolution, 20FPS @5MP, IR Viewable Length: 10m(32.8ft), BLC, Day & Night (ICR), WDR 120dB, Coaxial communication (ACP / Coaxitron), Selectable universal output (AHD / CVBS), IP66, IK10, Power 12VDC/24VAC, Operating Temperature -30°C ~ +55°C(-22°F ~ +131°F), hard coated dome bubble, white color

Available as Hanwha Vision part number HCF-8011RV.

Technical specifications

Video

Specification	Value
Imaging Device — Size	1/2.9"
Imaging Device — Type	CMOS
Resolution	2560×1944
Max. Framerate(NTSC/PAL)	20fps
Min. Illumination — Color(1/30sec, 30IRE)	0.5
Min. Illumination — BW(1/30sec, 30IRE)	0.005
Video Out	BNC: AHD/TVI/CVI/CVBS Selectable
Video Transmission Distance	300m(5C2V Coaxial Cable)

Lens

Specification	Value
Focal Length (mm)	1.16
Max Aperture Ratio (F number) — Wide	2.25
Angular Field of View — Horizontal	180°
Angular Field of View — Vertical	180°
Min. Object Distance	0.2m(0.66ft)

Operational

Specification	Value
Day & Night	Auto(ICR)
Backlight Compensation	BLC, WDR, SSDR
Wide Dynamic Range (dB)	120
Digital Noise Reduction	SSNRⅤ
Gain Control	Low, Middle, High
White Balance	ATW, AWC, Manual, Indoor, Outdoor
Electronic Shutter — Mode	Minimum, Maximum, Anti flicker
Electronic Shutter — Speed Range	1/30~1/50,000sec
Video Rotation	Flip, Mirror, Hallway view(90°/270°)
IR Viewable Length	10m(32.81ft)
Coaxial Protocol	ACP, CVBS

Environmental & Electrical

Specification	Value
Operating Condition — Temperature	-30°C~+55°C(-22°F~+131°F)
Operating Condition — Humidity	0~90% RH(non-condensing)
Storage Condition — Temperature	-50°C~+60°C
Storage Condition — Humidity	0~90% RH(non-condensing)
Input Voltage	24VAC, 12VDC
Power Consumption — 12VDC	6.5W
Power Consumption — 24VAC	5.4W

Mechanical

Specification	Value
Color	White
Material	Aluminum
RAL Code	RAL9003
Product Dimensions	ø145.9×65.8mm(ø5.74×2.59")
Product Weight	720g(1.59lb)

Certifications & Standards

Specification	Value
EMC	FCC 47 CFR 15 Subpart B Class A, ICES-3(A)/NMB-3(A)
Safety	UL 62368-1, CAN/CSA C22.2 NO. 62368-1, IEC 62471
Environment	EN IEC 63000, IEC 60529 IP66, IEC 62262 IK10

Ver

Specification	Value
Ver	202410

Specifications from official manufacturer documentation. Some values may vary by hardware configuration.

SKU: HCF-8011RV Categories: Analog HD Cameras, Video Cameras Brand: Hanwha

Hanwha HCF-8011RV 5MP IR Analog HD Fisheye Camera
