Pelco Esprit Compact Bispectral PTZ Camera
Pelco Esprit Compact Bispectral PTZ — 2MP visible + thermal (QVGA/VGA) in a single compact PTZ. IP66/67/68, MIL-STD-810H, Smart Analytics, railway EN50121-4 certified, NDAA compliant. 9Hz and 30Hz thermal frame rate options. SKUs: ESCE1-2X40V9-RLU, ESCE1-2X40V24-RLU, ESCE1-2X40Q6-RLU and more.
$16,264.00 USD
Pelco Esprit Compact Bispectral PTZ Camera (ESCE1 Bispectral Series)
The Esprit Compact Bispectral PTZ combines a 2 MP visible camera (40× optical zoom) with a thermal uncooled VOx microbolometer into a single compact PTZ housing. The thermal channel detects heat signatures at long distances in any weather or lighting condition, while the visual camera delivers identification-quality imagery. Rated IP66/67/68, MIL-STD-810H, and compliant with EN50121-4 for railway applications. NDAA Section 889 compliant.
- Visual: 2 MP, 1/2.8″ CMOS, 40× zoom (4.25–170mm, F/1.6), 120dB WDR, 0.03 lux, 60 fps, EIS, 12× digital zoom
- Thermal: uncooled VOx microbolometer, 12μm pixel pitch, 8–14μm spectral range, NETD ≤50mK; QVGA 320×256 or VGA 640×512
- Thermal lenses: 6.3mm/34° HFOV (QVGA), 8.7mm/50° HFOV (VGA), 24.4mm/18° HFOV (VGA); QVGA 18mm available — contact for pricing
- IP66/67/68, IK10; MIL-STD-810H, MIL-STD-167-1A; –40°C to +60°C; sustained 230 km/h wind; EN50121-4 railway
- Pelco Smart Analytics: auto-tracking, loitering, PPE detection; H.264 & H.265; ONVIF Profile G/M/S/T; FIPS 140-2 Level 3 (NXP TPM)
- 90W PoE (IEEE 802.3bt Class 8), 24 VDC, or 24 VAC; 500 presets; 10 tours; MicroSD storage; 5-year warranty
Part Numbers & Pricing
| Part Number | Thermal Sensor & Lens | Frame Rate |
|---|---|---|
| ESCE1-2X40V9-RLU | VGA 640×512 — 8.7mm (50°) | 30Hz |
| ESCE1-2X40V9-RLU-1 | VGA 640×512 — 8.7mm (50°) | 9Hz |
| ESCE1-2X40V24-RLU | VGA 640×512 — 24.4mm (18°) | 30Hz |
| ESCE1-2X40V24-RLU-1 | VGA 640×512 — 24.4mm (18°) | 9Hz |
| ESCE1-2X40Q6-RLU | QVGA 320×256 — 6.3mm (34°) | 30Hz |
| ESCE1-2X40Q6-RLU-1 | QVGA 320×256 — 6.3mm (34°) | 9Hz |
Note: ESCE1-2X40Q18-RLU / ESCE1-2X40Q18-RLU-1 (QVGA 18mm/12°) also available — contact us for pricing.
Technical specifications
Family specifications from the official Pelco datasheet. Manufacturer part number PELCO-ESCE1-BISPEC; some values vary by model variant — see the datasheet or ask us to confirm your exact configuration.
Thermal Camera
| Specification | Value |
|---|---|
| RUGGED FOR TOUGH CONDITIONS | Safe in extreme temperatures from -40°C to 60°C (-40°F to; 140°F), plus IP66/67/68 weather rating and IK10 impact rating |
| for maximum durability. | H.264 AND H.265, SMART COMPRESSION |
| minimize bandwidth and storage needs. | ONVIF® COMPLIANT*; ONVIF Profile S, T, G, and M conformance for easy |
| integration with any third-party VMS. | *ONVIF is a trademark of Onvif, Inc. |
| Image Sensor | 320 x 256 Uncooled VOx Microbolometer; 640 x 512 Uncooled VOx Microbolometer |
| Pixel Pitch | 12μm |
| Spectral Range | 8μm to 14μm |
| Aspect Ratio | 5:4 |
| Image Rate | Up to 30 fps (-1 models up to 8.6 fps) |
| Dynamic Range | -40°C to 225°C (-40°F to 437°F) [may vary based on operating temperature] |
| Resolution Scaling | 320 x 256, can be scaled up to 640 x 512 |
| 3D Noise Reduction Filter | Yes |
| Sensitivity | NETD ≤50 mK (NETD ≤40 mK when Frame Averager feature is enabled) |
| Image Uniformity Optimization | Automatic Flat Field Correction (FFC) – Thermal and Temporal |
Lens
| Specification | Value |
|---|---|
| 6.3 mm | 18 mm |
| 8.7 mm | 24.4 mm |
| Horizontal field of view | 34° |
| 12° | 50°; 18° |
| Vertical field of view | 27.2° |
| 9.6° | 37.5°; 13.5° |
| F-number | F/1.01 |
| F/1.04 | F/1.01; F/1.00 |
| identification) | 131m / 33m / 20m |
| 381m / 95m / 59m | 172m / 43m / 26m; 505m / 126m / 78m |
| identification) | 608m / 152m / 94m |
| 1753m / 438m / 270m | 867m / 217m / 133m; 2506m / 627m / 386m |
| Visible – Image Performance | 2.0 MP |
| Image Sensor | 1/2.8" progressive scan CMOS |
| Active Pixels (H x V) | 1937 (H) × 1097 (V) |
| Imaging Area (H x V) | 5.568 mm (H) × 3.132 mm (V); 0.219 ” (H) × 0.123 ” (V) |
| Minimum Illumination | 0.03 lux (F/1.6) in color mode; 0.02 lux; (F/1.6) in monochrome |
| Dynamic Range | 120 dB |
| Image Rate | Up to 60 fps |
| Aspect Ratio (Resolution Scaling) | Down to (16:9) 384×216 or (5:4) 320×256 |
| Signal Noise (S/N) Ratio | More than 50 dB |
Lens
| Specification | Value |
|---|---|
| Horizontal | 66.35° – 1.9° |
| Vertical | 39.99° – 1.11° |
| Visible – Image Performance | 2.0 MP |
| Zoom | Up to 40x |
| 3D Noise Reduction Filter | Yes |
| Visible – Image Control | 2.0 MP |
| Electronic Shutter Control | Automatic, Manual (1/1 to 1/10,000 sec) |
| Iris Control | Automatic, Open, Closed |
| Day/Night Control | Automatic, Manual |
| Flicker Control | 60 Hz, 50 Hz |
| White Balance | Automatic, Manual |
| Privacy Zones | 3D, up to 64 zones |
| Digital Zoom | 12X |
| Electronic Image Stabilization | Yes |
| Adjustable/Off | Common – Image Control |
| Video Compression | H.264 and H.265 Pelco Smart Compression, Motion JPEG |
| Streaming | Multi-stream H.264, Multi-stream H.265, Motion JPEG |
| Presets | 500 named presets |
| Tours | 10 named tours |
Network
| Specification | Value |
|---|---|
| Cabling Type | CAT5e/CAT6 shielded (STP) Ethernet cable is required to fully comply with EMC regulatory standards |
| Connector | RJ-45 |
| ONVIF | ONVIF compliance Profile G, Profile M, Profile S, and Profile T (www.onvif.org) |
| Protocols | IPv6, IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMPv3, ICMP, DHCP, |
| Device Management Protocols | SNMP v2c, SNMP v3 |
| Audio Input/Output | None |
| External I/O Terminals | 2 Alarm In, 2 Alarm Out |
| Onboard Storage | MicroSD/microSDHC/microSDXC slot – video speed class card required. Class V10 or better; recommended. |
Mechanical
| Specification | Value |
|---|---|
| Dimensions (Ø×H) | Ø240 mm × 406 mm; Ø9.45” × 16.0” |
| Weight | 7.4 kg; 16.3 lb |
| Glass Window | 6 mm thick (0.24") |
| Germanium Window | • Thick: 1.5mm (0.06in) |
| • Antireflection treatment | • Spectral range: from 7.5μm up to 14μm |
| Finish | Epoxy-polyester powder painted, close to RAL9002 |
| Tilt | Upright: -90° to +90°; Inverted: -40° to +90° |
| Pan | 360°, endless, up to 250°/second |
| Horizontal speed (variable) | from 0.1°/s up to 250°/s |
| Tilt speed (variable) | from 0.1°/s up to 250°/s |
| Accuracy of preset positions | ±0.1° |
Electrical
| Specification | Value |
|---|---|
| Power Consumption | 71 W max with 24 VDC aux power supply or 90 W PoE, 100 VA with 24 VAC aux power. UL rating as; specified on the product label = 5A max |
| External Power | •24 VDC, 24 VAC 50/60 Hz |
| •57 VDC PoE++, 71 W max | PoE; 90 W compatible with standard IEEE 802.3bt Class 8 |
| Power Connector | 2-wire terminal block, 18 AWG to 13 AWG |
| RTC Battery Backup | None |
Environmental
| Specification | Value |
|---|---|
| Operating Temperature | Continuous functioning: from -40°C (-40°F) up to +60°C (140°F). |
| Storage Temperature | -40 °C to +70 °C (-40 °F to 158 °F) |
Environmental
| Specification | Value |
|---|---|
| Humidity | 5% – 95% non-condensing |
| Cold Start | Up to 120 minute startup delay at temperature lower than -10 °C (14 °F) |
| Wind Resistance | Sustained 230 km/h (143 mph) |
Certifications
| Specification | Value |
|---|---|
| Safety | UL 62368-1, CSA 62368-1, IEC/EN 62368-1 |
| Environmental and Performance | UL/CSA/IEC/EN 62368-1 for outdoor enclosures, IEC 62262 IK10 Impact Rating (enclosure only), IEC |
| 60529 IP66, IP67, IP68 Weather Rating, | IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-30, |
| Electromagnetic Emissions | FCC Part 15 Subpart B Class A, IC ICES-003 Class A, EN 55032 Class A, EN 61000-6-4, EN 61000-3-2, |
| EN 61000-3-3, EN 50121-4 | Electromagnetic Immunity; EN 55035, EN 50130-4, EN 50121-4 |
| Warranty | 5-year limited warranty. Extended warranty not available. |
| Railway Applications | Compliance to railway application standard: EN50121-4 |
| MM | 406[16] |
| 318[12.5] | 219[8.6] |
| 231[9] | 170[6.7] |
| [1.8] | 438[17.2] |
| Ø240 | [9.4] |
| Ø340 | [13.4] |
| Weight | 8 lbs |
|---|---|
| Dimensions | N/A |
| Thermal Sensor & Lens | VGA 640×512 — 8.7mm (50°), VGA 640×512 — 24.4mm (18°), QVGA 320×256 — 6.3mm (34°) |
| Frame Rate | 30Hz, 9Hz |
| Warranty | 5 Years |
